The grinding media (rods, segments, balls) in the grinding cylinder do strong projectile motion, high-speed rotation motion and slow-speed revolution motion under the high-frequency vibration of the high-speed vibration exciter (or vibration motor). The material causes strong impact, friction, and shearing, so that the material is ultra-finely crushed and uniformly mixed.
Product description
The grinding media (rods, segments, balls) in the grinding cylinder do strong projectile motion, high-speed rotation motion and slow-speed revolution motion under the high-frequency vibration of the high-speed vibration exciter (or vibration motor). The material causes strong impact, friction, and shearing, so that the material is ultra-finely crushed and uniformly mixed.
Performance characteristics
Working principle
With the high-speed vibrator or vibration motor, the grinding media (pins, cylpebs or balls) would vibrate in high frequency, high-speed rotating and slow revolving, which would impact, rub and shear materials around them and make them into fine powder and mix them evenly.
Technical parameter
Medium and small Amplitude Vibration Mill Technical Parameter
Parameter | MZ10 | MZ30 | MZ50 | MZ100 | MZ200 | MZ300 | MZ500 |
Chamber Volume(L) | 10 | 30 | 50 | 100 | 200 | 300 | 500 |
Input Particle Size (mm) | 5 | 5 | 5 | 10 | 10 | 10 | 10 |
Produce Size (μm) | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 |
Production Capacity (kg/h) | 1-5 | 5-20 | 10-50 | 20-150 | 50-300 | 100-500 | 150-800 |
Power (kW) | 0.75 | 1.5 | 2.2 | 3.7 | 7.5 | 11 | 15 |
Big Amplitude Vibration Mill Technical Parameter
Parameter | MZ100 | MZ300 | MZ500 | MZ600 | MZ800 | MZ1000 | MZ1200 | MZ2000 |
Chamber Volume(L) | 100 | 300 | 500 | 600 | 800 | 1000 | 1200 | 2000 |
Input Particle Size (mm) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
Produce Size (μm) | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 | 10-150 |
Production Capacity (kg/h) | 100-200 | 200-300 | 300-600 | 400-800 | 500-1000 | 800-1500 | 1000-1800 | 2000-3000 |
Power (KW) | 15 | 45 | 55 | 75 | 90 | 110 | 150 | 220 |
